Features of Label Flexographic Printing Machine:
1. Adopt the ceramic anilox roller to transfer the ink.
2. Unwinding and rewinding are controlled by magnetic powder brake/clutch.
3. Each printing unit adopts 360°plate-adjustment.
4. Each printing unit is equipped with IR dryer
5.This printing machine equips one die-cutting station to complete printing and die-cutting at one stroke.
6. The ink rollers will be separated from the printing rollers, and keep running when the machine stops.
7. Main motor adopts imported inverter.
Applications of Label Flexographic Printing Machine:
1. This kind of converting machinery is widely used to print notes and top-grade adhesive labels for printing houses.
2. It can perform the processes of material-feeding, printing, varnishing, drying, laminating, die-cutting, rewinding and sheetering in one go.
| Model | ZBS-320 | ZBS-320G |
| Printing speed: | 50m/min | 55m/min |
| Printing colour : | 5colours | 5colours |
| Max. web width : | 320mm | 320mm |
| Max. printing width: | 310mm | 310mm |
| Max. unwinding diameter: | 600mm | 650mm |
| Max. rewinding diameter: | 600mm | 650mm |
| Printing perimeter: | 175-355mm | 175-355mm |
| Precision of chromatography: | ±0.1mm | ±0.1mm |
| Dimensions: | 2(L)x1.1(W)x2.6(H)(m) | 2.6(L)x1.1(W)x2.6(H)(m) |
| Machine weight: | about 2200kg | about 3100kg |
